Selecting a Wedge Bonder

Posted by Katie Finney on Tue, May 12, 2015 @ 01:00 PM

Palomar/Hughes started designing and manufacturing wedge bonders in the early 1980s for the aerospace and defense industries. Later, these machines were used for a wider array of applications beyond just military, including medical devicesRF/Wireless packages, automotive sensor systems, and optoelectronic systems and components. Ultrasonic wedge bonding was introduced in the early 1960s.

Automated wire bonders were first introduced nearly 40 years ago. At this time, the majority of interconnects were made using aluminum wire. As the need for high reliability increased, gold wire became more common. As package densities increased, wire interconnect bond pitches decreased. The initial solution to the fine pitch challenge was wedge bonding due to the design of the wedge tool allowing wires to be bonded in close proximity (side-by-side).

Throughout the years, several features have remained common among wedge bonding equipment such as wire fed through the tool and the wire clamping behind the tool. Today's wedge bonders are vastly different from those of the past, as well as performance capabilities differing from manufacturer to manufacturer. When selecting a wedge bonder, you should consider the following criteria:

Criteria #1: Capability to handle gold, aluminum, and ribbon wire

Almost every wedge bonder is capable of handling all three types of wire. However, modern wedge bonders, such as our 9000 Wedge Bonder, can handle all three wire types without changing the wire clamp.

9000 wire clamp.jpg

Criteria #2: Better control on wire feed

Older wedge bonders have longer wire spans from de-spooler to wire clamp which renders poor control of the wire feed. The wire—especially ribbon wire—can easily be twisted and affect the bonding quality. The advanced wedge bonders of today have overcome such obstacles.

Criteria #3: Easier conversion between different wire feed angles

Older wedge bonders are designed to specifically cater to one type of wire feed angle. If you have a wedge bonder equipped with a 45-degree wire feed angle, you cannot use it for deep access bonding applications without replacing the entire bond head with a deep access wire clamp. Not only is this costly, but it is also very time consuming to change the bond head because the bonder may have to stop production for a couple of days during the conversion. The good news: modern wedge bonders have done away with bond head changes and are now capable of converting from a 45/60-degree to 90-degree wire feed.


Criteria #4: User-friendly programming

Programming wires can become a nightmare, particularly when the number of wires runs into the hundreds and thousands. Our modern wedge bonders are now equipped with user-friendly Intelligent Interactive Graphical Interface® (i2Gi®) as a standard feature which allows the management from part design and development, to process validation and finally to intuitive operations control.

Criteria #5: Contactless height learning saves time

Older wedge bonders use a physical contact to learn the heights of the surface to be bonded when learning or transferring programs onto a machine. The method is slow, time-consuming, and can cause damage to the parts. However, modern wedge bonders are intelligent enough to learn the heights without having to make physical contact with the parts providing protection to the valuable parts. The 9000 Wedge Bonder has auto focus with part height update which is useful during production runs to better handle part height variations.


Download these resources for more information:

9000 Data Sheet The Buyer's Guide to Microelectronics Packaging Equipment eBook i2Gi® Data Sheet
9000 Wedge Bonder data sheet Modern Wedge Bonding eBook i2Gi, intelligent interactive graphical interface, modern wire bond control software


PH Chan 钟碧和
General Manager, Asia-Pacific
Palomar Technologies Asia
